Alfa Romeo Wheel Bearing and Hub Assembly
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M14x1.5
Brake Pilot Diameter
70
Flange Bolt Hole Quantity
4
Flange Diameter
135
Flange Offset
38.5
Hub Pilot Diameter
92
Wheel Pilot Diameter
65
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
110
Bolts Included
No
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Height
76.5
Spline Quantity
30
Wheel Studs Included
No
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2012-2012 | Alfa Romeo | 159 | Rear, Front | |
2007-2008 | Alfa Romeo | 159 | Rear, Front | |
2007-2008 | Alfa Romeo | Brera | Rear, Front | |
2007-2008 | Alfa Romeo | Spider | Front, Rear |
