Buick, Chevrolet (1.8) Wheel Bearing and Hub Assembly Repair Kit - Front
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M12x1.5
Brake Pilot Diameter
71
Flange Bolt Hole Quantity
3
Flange Diameter
146
Flange Offset
42
Hub Pilot Diameter
91.3
Wheel Pilot Diameter
70
Wheel Studs Included
Yes
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
115
Bolts Included
No
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Height
103.6
Spline Quantity
30
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2012-2012 | Buick | Verano | Front | |
2012-2013 | Chevrolet | Orlando | Front | |
2011-2013 | Chevrolet | Volt | Front | |
2010-2012 | Chevrolet | Cruze | Base | Front |
2010-2016 | Chevrolet | Cruze | LS, LT | Front |
