Toyota (1.8, 2.0 - FWD) Wheel Bearing and Hub Assembly
SPECIFICATIONS
ABS Tone Ring Tooth Quantity
48
Anti Lock Braking System Type
Encoder
Bearing Type
Ball
Bolt Thread Pitch
M12x1.5
Brake Pilot Diameter
55
Flange Bolt Hole Quantity
3
Flange Diameter
135
Flange Offset
47.5
Hub Pilot Diameter
85
Wheel Pilot Diameter
54
Wheel Studs Included
Yes
Anti Lock Braking System
Yes
Bearing Generation
Gen 3
Bolt Circle Diameter
100
Bolts Included
No
Driven Type
Driven
Flange Bolts Included
No
Flange Included
Yes
Height
94
Spline Quantity
26
Wheel Stud Quantity
5
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2023-2024 | Toyota | Corolla | Hybrid XLE, Base, LE, XLE | |
2022-2022 | Toyota | Corolla | XLE | |
2021-2024 | Toyota | Corolla | Hybrid LE, SE | |
2021-2022 | Toyota | Corolla | Base, LE | |
2020-2022 | Toyota | Prius | Base, Premium | |
2019-2023 | Toyota | Corolla | Front | |
2019-2022 | Toyota | Prius AWD-e | Front | |
2017-2022 | Toyota | Prius Prime | Front | |
2016-2018 | Toyota | Prius | Base, Premium | |
2016-2022 | Toyota | Prius | Front |
