Countryside Road

Honda (Drum) Wheel Bearing and Hub Assembly - Rear

Part Number:

9230069

Product Type:

Hubs and Related Components

​

SPECIFICATIONS

ABS Tone Ring Tooth Quantity

48

Anti Lock Braking System Type

Encoder

Bearing Type

Ball

Brake Pilot Diameter

61

Flange Bolt Hole Quantity

4

Flange Offset

56

Spline Quantity

30

Wheel Stud Thread Size

M12x1.5

Anti Lock Braking System

Yes

Bearing Generation

Gen 2

Bolt Circle Diameter

100

California Proposition 65

Yes

Flange Diameter

139

Prop 65 Yes/No

Yes

Wheel Pilot Diameter

56

FEATURES & BENEFITS

​

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2019-2022
Honda
Insight
Rear
2010-2014
Honda
Insight
Rear
2009-2014
Honda
Fit
Rear
2006-2008
Honda
Fit
Rear
