12-15 Audi A1 (1.4) CV Axle Assembly - Front Right
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
22
Axle Nut Thread Size
M16×1.5
Boot Color
Black
Compressed Length
30.91
Inboard Spline Quantity
0
Outboard Spline Quantity
36
Axle Nut Included
Yes
Axle Nut Socket Size
41
Axle Nut Type
Bihexagonal
Boot Material
Neoprene
Inboard Joint Type
Flange
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
---|---|---|---|---|
2012-2015 | Audi | A1 | Front Right |
