Toyota (4WD) CV Axle Assembly - Front
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
16
Axle Nut Thread Size
M28×1.5
Boot Color
Black
Compressed Length
24.76
Inboard Spline Quantity
30
Outboard Spline Quantity
30
Axle Nut Included
Yes
Axle Nut Socket Size
35
Axle Nut Type
Hex
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
---|---|---|---|---|
