01-05 Kia Rio CV Axle Assembly - Front Left
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
29
Axle Nut Type
Hex
Compressed Length
23.82
Inboard Spline Quantity
26
Outboard Spline Quantity
24
ABS Tone Ring Tooth Quantity
44
Axle Nut Length
22.5
Axle Nut Thread Size
M20×1.5
Boot Material
Neoprene
Inboard Joint Type
Male
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2002-2005 | Kia | Rio | Base, Cinco | Front Left |
2001-2001 | Kia | Rio | Front Left |
