10-13 Kia Sportage (2.0 - AWD) CV Axle Assembly - Rear Left

Part Number:

224524

Product Type:

CV Components

SPECIFICATIONS

ABS Tone Ring Included

Yes

Axle Nut Included

Yes

Axle Nut Socket Size

32

Axle Nut Type

Hex

Compressed Length

32.95

Inboard Spline Quantity

25

Outboard Spline Quantity

27

ABS Tone Ring Tooth Quantity

48

Axle Nut Length

21

Axle Nut Thread Size

M22×1.5

Boot Material

Neoprene

Inboard Joint Type

Male

Outboard Joint Type

Conventional

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2010-2013
Kia
Sportage
Rear Left
