Countryside Road

Hyundai, Kia (2.0 - FWD) CV Axle Assembly - Front Right

Part Number:

224230

Product Type:

CV Components

SPECIFICATIONS

ABS Tone Ring Included

Yes

Axle Nut Included

Yes

Axle Nut Socket Size

31.5

Axle Nut Type

Hex

Compressed Length

37.83

Inboard Spline Quantity

27

Outboard Spline Quantity

27

ABS Tone Ring Tooth Quantity

48

Axle Nut Length

21

Axle Nut Thread Size

M22×1.5

Boot Material

Neoprene

Inboard Joint Type

Male

Outboard Joint Type

Conventional

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2011-2015
Kia
Sportage
Front Right
2010-2013
Hyundai
Tucson
Front Right
2010-2011
Hyundai
ix35
Front Right
