16-22 Honda HR-V (AWD) CV Axle Assembly - Rear Left
SPECIFICATIONS
ABS Tone Ring Included
NO
Axle Nut Length
20
Axle Nut Thread Size
M22×1.5
Boot Material
TPE
Inboard Joint Type
Male
Outboard Joint Type
Conventional
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Compressed Length
787
Inboard Spline Quantity
20
Outboard Spline Quantity
23
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
2016-2022 | Honda | HR-V | Rear Left |
