Ford, Mercury CV Axle Assembly
SPECIFICATIONS
ABS Tone Ring Included
Yes
Axle Nut Included
Yes
Axle Nut Socket Size
32
Axle Nut Type
Hex
Compressed Length
22.36
Inboard Spline Quantity
35
Outboard Spline Quantity
27
ABS Tone Ring Tooth Quantity
44
Axle Nut Length
15
Axle Nut Thread Size
M22×1.5
Boot Material
Neoprene
Inboard Joint Type
Female
Outboard Joint Type
Conventional
FEATURES & BENEFITS
APPLICATIONS
Year Range | Make | Model | SubModels | Position |
|---|---|---|---|---|
1999-2000 | Mercury | Mystique | Front Right | |
1999-2002 | Mercury | Cougar | Front Right | |
1998-1998 | Mercury | Mystique | LS | Front Right |
1998-2000 | Ford | Contour | SVT | Front Right |
1998-1998 | Ford | Contour | SE | Front Right |
1997-1997 | Ford | Contour | Sport | Front Right |
1996-1997 | Ford | Contour | SE | Front Right |
1996-1998 | Ford | Contour | GL, LX | Front Right |
1996-1996 | Ford | Contour | Sport | Front Right |
1995-1997 | Mercury | Mystique | Front Right | |
1995-2000 | Ford | Contour | Front Right | |
1995-1995 | Ford | Contour | Front Right |
