Countryside Road

19-22 Hyundai HB20X (1.6) CV Axle Assembly - Front Left

Part Number:

203535

Product Type:

CV Components

SPECIFICATIONS

ABS Tone Ring Included

Yes

Axle Nut Included

Yes

Axle Nut Socket Size

32

Axle Nut Type

Hex

Compressed Length

36.1

Inboard Spline Quantity

27

Outboard Spline Quantity

25

ABS Tone Ring Tooth Quantity

48

Axle Nut Length

24

Axle Nut Thread Size

M22×1.5

Boot Material

Neoprene

Inboard Joint Type

Male

Outboard Joint Type

Conventional

FEATURES & BENEFITS

APPLICATIONS

Year Range
Make
Model
SubModels
Position
2019-2022
Hyundai
HB20X
Front Left
